Laser Particle Sensor
PM2008-APIPM2008-API

PM2008-API laser particle sensor module is based on laser scattering technology, ultra-thin (12mm) designed with all metal shielding. Detecting particle concentration size between 0.3μ-10μm in the air and real-time output PM1.0、PM2.5、PM10 in μg/m3 via mathematical algorithm and scientific calibration.

Product Inquiry

Features

Real-time output PM1.0、PM2.5、PM10 in μg/m3 available
All metal shielding, strong anti-interference
Smaller and thinner structure design, height only 12mm
High accuracy, high sensitive and quick response (≤8s)
Signal output optional: UART, I²C

Specifications

	CO2 Sensor CM1106-C
Measured particle size	0.3μm~10μm
Measurement range	0~5000μg/m³
Measurement accuracy for PM1.0&PM2.5	0 ~35μg/m³, ±5μg/m³ 35μg/m³~500μg/m³, ±15% of reading
Measurement accuracy for PM10	0~100μg/m³, ±30μg/m³ 101 ~500μg/m³, ±30% of reading
Condition	25±2℃,50±10%RH
Reference instrument	GRIMM
Dust Source	Cigarette +Arizona A1
Time to first reading	≤8s
Response time	1s
Working temperature	-10℃~60℃
Working humidity	0~95%RH(non-condensing)
Power supply	DC5V±0.1V
Ripple wave	<50mV
Working current	<100mA(working); <200μA(standby)
Signal output	UART_TTL, I²C, PWM(customized)
Dimensions	W47.8H36.8D12(mm)
